Brochure: Pages 10 & 11

Description:
• Multiple Job Storage – Storage for up to 200 jobs is standard.
• Micro Adjust – New parameters allow for micro adjustment of the feed distance as the feed is running.
• Back Length – Used in Cut-To-Length or Cut-Off applications, this feature backs the material away from the blade allowing the blade to be raised without lifting the fresh cut edge of the material – particularly useful for thin or delicate material.

FULL PRODUCT DESCRIPTION

MODEL ADVANTAGE
All of our mechanical assemblies are made from heavy cast frames, stabilized and then machined. The rugged design of our servo roll feeds eliminates maintenance. And P/A Industries includes user-friendly features at no extra charge like catenary, quick-release handles to adjust roller stock guides, exit support and stock buckle bridge, transition mounting brackets, positive pilot release roller cam and roll release lever for material insertion.

MECHANICAL FEATURES
• Rugged Steel Frame
• Unique Design Maintains Roll Parallelism with Off Centre Loading
• Precision Gear Driven Upper Roll with Anti-Backlash
• Roll Release Lever for Strip Insertion with Safety Lock
• Stock Thickness Adjustment Lever
• Large Diameter, Hard Chrome Feed Rolls are Texturized for Increased Grip
• Feed Mounting Bracket For 2.4” (61 mm) of Die Height Adjustment
• Pilot Release Roller Cam
• Exit Support Bridge to Prevent Stock Buckling
• Feed Rolls Mounted in Permanently Sealed, Anti-Friction Ball Bearings
• Precision Planetary Gearbox 5:1 Ratio
• Precision Planetary Gearbox 8:1 Ratio for Models SRF28 – 36
• “X” Model offers a standard 8:1 Gearbox and extra thickness capacity

ELECTRONIC FEATURES
• ISO Certified Electrical Components Wired to JIC, NEC, & CE Standards
• Backlit, LCD Touchscreen Display
• Built-In I/O Diagnostics Assists in Troubleshooting
• Batch Counter
• Password Protected Job Storage
• On-The-Fly, Micro Adjust Feed Length
• Inch/Metric, Multi-Language Select ability
• Single Stroke or Continuous Press Mode Capability
• Jog Pendant
• Jog-To-Length Capability
• High Performance Digital Servo Drive and Motor
• NEMA 4/12/13 Enclosure
• Free Standing and Portable Console Stand
• Mushroom Emergency Stop with Auxiliary Contacts for Multi-Unit Stop
• Lockable Power Disconnect Switch
