BSTA 810
- High performance stamping press with perfected mass balancing system and adjustable stroke
- Press force 810 kN
- Speeds ranging:
- BSTA 810-124: 100 – 1000 spm
- BSTA 810-145: 100 – 1000 spm
- BSTA 810-180: 100 – 950 spm
- Modular design in 4 versions
- Bolster plate dimensions:
- BSTA 810-124: 1220 x 910 mm
- BSTA 810-145: 1430 x 910 mm
- BSTA 810-180: 1790 x 910 mm
- Control based on IPC, high-quality TFT display with long service life and even illumination for good readability even under difficult lighting
- Integrated safety control
- Signal transmission to the stamping press via EtherCAT bus system
- Precision mechanics, versatile – can be used for a number of different applications, optimum cost-benefit ratio
- Description
- Reviews (0)
Description
The BSTA 810 high-performance stamping press is built for maximum productivity in high-volume series production. Featuring a nominal press force of 810 kN, variable stroke heights and a tooling loading area of up to 1800 mm, it offers exceptional versatility across a wide range of applications. With stroke rates of up to 1000 spm, it delivers both speed and precision. The adjustable stroke ensures optimal adaptation to a wide range of applications, while integrated press force monitoring and advanced drive technology guarantee maximum precision, process reliability, and energy efficiency.
