Brochure: Pages 12 & 13

Description:
• Rugged Steel Frame
• Unique Design Keeps Roll Parallelism w/ Off Center Loading
• Precision Gear Driven Upper Roll w/ Anti-Backlash
• Pneumatic Pilot Release of Upper Rolls for Strip Insertion
• Batch Counter
• On-The-Fly, Micro Adjust Feed Length
FULL PRODUCT DESCRIPTION
MODEL DYNAMAX
MECHANICAL FEATURES
•Rugged Steel Frame
•Unique Design Maintains Roll Parallelism with Off
Center Loading
•Precision Gear Driven Upper Roll with Anti-Backlash
•Pneumatic Cylinders to provide Roll Pressure
•Pneumatic Pilot Release of Upper Roll for Strip Insertion and Piloting
•Smooth Finish Hard Chrome Feed Rolls
•Feed Mounting Bracket For 4.0” (102 mm) of Die
Height Adjustment
•Exit Support Bridge to Prevent Stock Buckling
•Feed Rolls Mounted in Permanently Sealed, Anti-Friction Ball Bearings
•Precision Planetary Gearbox 7:1 Ratio
ELECTRONIC FEATURES
•ISO Certified Electrical Components Wired to JIC, NEC & CE Standards
•Backlit, LCD Touchscreen Display
•Built-In I/O Diagnostics Assists in Troubleshooting
•Batch Counter
•Password Protected Job Storage
•On-The-Fly, Micro Adjust Feed Length
•Inch/Metric, Multi-Language Selectability
•Single Stroke or Continuous Press Mode Capability
•Jog Pendant
•Jog-To-Length Capability
•High Performance Digital Servo Drive And Motor
•NEMA 4/12/13 Enclosure
•Free Standing and Portable Console Stand
•Mushroom Emergency Stop with Auxiliary Contacts for Multi-Unit Stop
•Lockable Power Disconnect Switch
