ZUB 250 (FMS-Q 250 RS)
Stamping and bending machine with a production speed of 360 pieces/min depending on the tool and component part.
With regard to the size of construction this machine is similar to the Finzer machine ZUB 250.
Precision grip feeder permits a repeat
precision of 0.01 mm. The max.
feeding length is 500 mm
• Stamping unit of 250 kN with a stroke
of 15/20 mm
• Quick-change-plate equipped with up to
11 positively controlled bending slides
requiring low maintenance, (bending
force of 30/50 kN with a stroke of
45 mm) with a work and a return cam
• Processing of strip material of a width of up to 60 mm (special
versions of a width of up to 120 mm)
and a thickness of 2.5 mm as well as wires of a Ø of up to 6 mm
• RPM-regulated drive of a power of 15 kW
