ZUB 700 (FMS Q700 RS)

ZUB 700 (FMS Q700 RS)

Stamping and bending machine with a production speed of 180 pieces/min depending on the tool and component part.

With regard to the size of construction this machine is similar to the Finzer machine ZUB 700.

Precision grip feeder permits a
repeat precision of 0.01 mm.
The max. feeding length is 500 mm

• Equipped with up to 11 positively controlled bending slides requiring low
maintenance (bending force of
40/60 kN with a stroke of 65 mm) with a work and a return cam

• Stamping unit of 700 kN with a stroke of 25 mm
» Stamping unit available with an overall width of either 800 mm or
1200 mm

• Processing of strip material of a width of up to 60 mm (special versions of a width of up to 120 mm)
and a thickness of 3 mm as well as wires of a Ø of up to 8 mm

• RPM-regulated drive of a power of 50 kW

• horizontally adjustable bending module
